LINK LABEL  ISH 330 Cross Cutter

  This machine is designed for precise cross cutting of printed and unprinted materials and is especially well suited for short runs, variable cutting lengths and transparent substrates.   Technical Specifications Unwinding System → Integrated unwinding unit → Loop control for stable web tension → Roll end sensor included Maximum Roll Diameter → 550 mm Maximum Web Width → 330 mm Cutting Length → Variable, programmable via touch screen → Skip function included → Intermediate cut programmable from 0.10 mm to 50.00 mm Maximum Speed → Up to 500 cuts per minute Drive and Control → Computer-controlled drive system → Touch screen operation Material Handling → Suitable for transparent materials → Suitable for printed and unprinted materials → Optical sensor for register control Delivery System → Delivery conveyor for shingled output → Pulse separation system for reliable product separation Infeed and Web Control → Pneumatic pressure rollers → Web tension control via integrated vacuum system → Vacuum pump included Electrical and Air Requirements Power Supply → 220 V → 10 A Compressed Air → Minimum 6 bar Dimensions and Weight Overall Dimensions (L x W x H) → 1,980 x 900 x 1,038 mm Machine Weight → Approx. 250 kg Why This Machine? The ISH 330 Cross Cutter stands out due to its high cutting accuracy, flexible length programming and excellent web control. Thanks to its optical register system and vacuum-controlled tension, it delivers consistent results even at high speeds and when processing challenging materials such as transparent films. Its compact footprint and intuitive touch screen operation make it an ideal solution for efficient finishing in modern label production environments.
