GALLUS T 180 – SCREEN AND LETTERPRESS LABEL PRINTING MACHINE WITH HOT-FOIL STAMPING, EMBOSSING AND FLATBED DIE-CUTTING

SCREEN AND LETTERPRESS LABEL PRINTING MACHINE WITH HOT-FOIL STAMPING, EMBOSSING AND FLATBED DIE-CUTTING

We are pleased to offer the following versatile GALLUS T 180, designed for the production and finishing of high-quality narrow-web labels.

The machine combines three screen-printing units with one letterpress printing unit, UV curing, hot-foil stamping, embossing and flatbed die-cutting. Thanks to the integrated unwinding and rewinding system, finished rolls can be produced directly within the machine in one complete production process.

MACHINE RATING

FGT Machine Rating: ⭐⭐⭐⭐⭐⭐⭐☆☆☆ 7/10

A solid and versatile specialist machine with proven Gallus engineering, particularly attractive for applications requiring screen printing, hot-foil stamping, embossing and inline finishing.

MACHINE DETAILS

• Manufacturer: Gallus
• Model: T 180
• Year of manufacture: 1996
• Web width: 180 mm
• Printing processes: Screen printing and letterpress printing
• Printing units: 3 screen-printing units + 1 letterpress unit
• Machine rating: 7/10
• Availability: By arrangement

TECHNICAL CONFIGURATION

Printing Units

• 3 screen-printing units
• 1 letterpress printing unit
• Suitable for high-opacity inks, solid colours and detailed print applications
• Combination of screen and letterpress printing within one production line

Drying System

• UV curing system
• Immediate curing of inks and varnishes
• Suitable for direct inline finishing and further processing

Varnishing

• Varnishing capability within the letterpress printing unit
• Suitable for protective and decorative varnish applications
• Inline finishing without the need for an additional standalone varnishing machine

Decorative Finishing

• Hot-foil stamping unit
• Embossing capability
• Suitable for metallic, decorative and tactile finishing effects
• Particularly attractive for premium and specialty label applications

Web Handling

• Unwinding unit
• Rewinding unit
• Controlled material transport through the complete production process
• Finished rolls can be produced directly in the machine

Die-Cutting

• Flatbed die-cutting unit
• Suitable for precise die-cutting of different label shapes and materials
• Inline production from raw material to finished rolls

WHY THIS GALLUS T 180?

✔ Combination of Screen and Letterpress Printing
The machine combines three screen-printing units with one letterpress printing unit. Screen printing is particularly suitable for strong colour coverage, high-opacity white, tactile ink layers and special-effect applications. The letterpress unit complements this with sharp text, fine lines and precise detail reproduction.

✔ Premium Decorative Finishing
The integrated hot-foil stamping and embossing equipment enables high-value decorative and tactile effects to be applied directly within the machine.

Typical applications include:

• Wine and spirits labels
• Cosmetic labels
• Pharmaceutical labels
• Luxury product labels
• Promotional and specialty applications

✔ High-Opacity Screen Printing
The three screen-printing units provide excellent ink coverage and allow thicker ink layers than conventional printing processes. This represents a significant advantage for opaque whites, solid colours, tactile effects, security inks and specialty coatings.

✔ Inline Varnishing
The letterpress unit can also be used for varnishing applications. Labels can therefore be printed, protected and visually enhanced within one continuous production process.

✔ Hot-Foil Stamping and Embossing
The combination of metallic foil effects and raised or recessed embossing adds considerable value to the finished product. These finishing processes are especially important for premium labels where appearance and tactile quality are key selling points.

✔ Flatbed Die-Cutting
The flatbed die-cutting unit provides accurate and reliable processing of a wide range of label shapes and materials. It is particularly suitable for specialty formats and demanding converting applications.

✔ Production of Finished Rolls
A significant advantage is the possibility of producing finished rolls directly within the machine. Unwinding, printing, varnishing, decorative finishing, die-cutting and rewinding can be completed in one production line.

✔ Proven Gallus Construction
Gallus machines are internationally recognised for their robust mechanical construction, production reliability and long service life. The GALLUS T 180 remains an interesting production platform for specialist label manufacturers requiring screen printing and premium finishing capabilities.

FGT MACHINE RATING – 7/10 ⭐

• ✔ Proven and robust Gallus mechanical construction
• ✔ Strong configuration for specialty and premium labels
• ✔ 3 screen-printing units provide considerable application flexibility
• ✔ Integrated hot-foil stamping and embossing add significant product value
• ✔ Complete inline production including flatbed die-cutting and rewinding
• ✔ Attractive solution for niche and specialty label production
• ➜ Rating reflects the machine’s age while recognising its strong specialist configuration
